Horn speaker JBL CSS-H15

All about product
Specification
Reviews
0
Questions
0
Information
Ends
In Stock
Product Code: 226030
Brand: JBL
Reviews: 0
Found cheaper?
3 522 ₴
Specifications: (See all)
Type
Horn
Body Material
ABS plastic
Number of Way
1
Tweeter, inch
1.3
Power, W
15
Coverage
70° x 90°
Description

The Commercial Solutions Series JBL CSS-H15 Paging Horn provides excellent voice range clarity for public address systems, announcement/paging, intercom, security, alarm and industrial applications. Designed for demanding environmental conditions, the CSS-H15 is highly weather resistant (IP-65 rated) so it can be used in either indoor or outdoor applications. The wide coverage pattern allows the horn to cover a larger audience area than is the case with many paging horns.

Features

  • Excellent voice range clarity for announcement and paging
  • High sensitivity delivers high sound levels with minimal power amplification
  • Wide 70° horizontal by 90° vertical coverage for medium throw applications
  • Phenolic diaphragm driver for outdoor durability and high reliability
  • UL-registered 15-watt multi-tap transformer, with 8 ohm direct bypass
  • Built-in high-pass filter enhances reliability by protecting against low frequency damage
  • Highly weather-resistant, with stainless steel bracket and hardware

Applications

  • Public Access Areas
  • Warehouses
  • Factories
  • Schools
  • Recreational Facilities
  • Commercial Buildings
  • Distribution Centers
  • Civic Centers
  • Other Commercial Sound and Protective Signaling Systems

User Manual

Specifications
[SE] Installation Acoustics
Type
Horn
Body Material
ABS plastic
Number of Way
1
Tweeter, inch
1.3
Power, W
15
Coverage
70° x 90°
Frequency Range
400 Hz - 7.5 kHz
Sensitivity, dB
105
Sound Pressure Level, dB
117
Marking
Dimensions, mm
163 x 222 x 232
Weight, kg
1.36
Equipment
Stainless steel mounting bracket
Warranty, month
12
Color
White
Brand Registration Country
USA
Country of origin
China
Reviews
0 / 5
average product rating
0
0
0
0
0

There are no reviews for this product, be the first to leave your review.

Answers & questions

No questions about this product, be the first and ask your question.
